Cross Roller Bearing Table
2-axis Precision Roller Linear Guides
2-axis Precision Ballscrew and Servo Motor Driven
Mitsubishi Color Touch Screen and Tech Interface
Variable Spindle and Table RPM
Tapered Surface Grinding
Auto Dress and Auto Compensation
Optional Equipment:
Auto Wheel Balancer
Table Diameter: 31.5″
Max cross travel: 23.6″
Max table load: 1984 lbs
Distance-Spindle Center to Table: 23.6″
Table Speed: 10-100″
Crossfeed MPG x1, x10 1 gra.: 0.00005″/0.0005″
Crossfeed MPG x1, x10 1 rev.: 0.005/0.05″
Crossfeed auto increment: 0.0005-1″
Grinding Wheel Spindle Speed: 0-1800 rpm
Grinding Wheel Dimension (Dia. x W x Bore): 16″ X 3.1″ X 5″
Spindle Motor: 15HP
Elevation in-feed MPG x1, x10 1 gra.: 0.00005/0.0005″
Elevation in-feed MPG x1, x10 1 rev.: 0.005/0.05
Auto Downfeed Increment: 0.00005-2.5″
Gross Weight: 14,330 lbs
