20” x 25” New Marvel Vertical Tilt-Frame Band Saw Model 2150M USA Made! Specifications:
20” x 25” New Marvel Vertical Tilt-Frame Band Saw Model 2150M USA Made! Features:
SPEED RANGE: 30 – 500 fpm (9 – 152 m/min), 10 HP standard. Blade speed can be automatically set when material is selected
TILTING COLUMN: For miter cutting up to 60° left and right of vertical. Now with Electronic Tilt, the column is electrically powered with encoder feedback and PC3 touch screen controller for precision miter positioning
0° – 3° CANTED COLUMN: Standard 3º forward approach angle, for increased efficiency in cutting off structural materials
BLADE GUIDE: Patent pending Rotating Easy Load Combination Carbide and Ball Bearing Roller guides with self-tensioning design
UPPER BLADE GUIDE ARM: Hydraulically positioned and locking, controlled by selector switch at operation’s station
FLUSHING HOSE: Washes chips from hard to get at places reducing clean-up time
WORK-REST ROLLERS: Two turned ball bearing rollers, one on the entry side and one on the discharge side of the machine bed
VISES: Hydraulic, full stroking with 9-1/2″ high x 15″ wide 60º faceplates. Removable face plates without tools to allow for both miters and 90º at the blade
PC3 PROGRAMMABLE CONTROL®: Provides a Programmable Logic Control Unit with a 12” color, touch screen display. The control features graphical part programming with memory for up to 500 jobs and parts, as well as a material selection chart and customizable material library
AUTOMATIC BAR FEED: The patented automatic bar feed design features a 48″ stroke length with indexing speeds of up to 60fpm. The bar feed is servo driven with encoder feedback, and combines precision double ball screws with preloaded recirculating linear guides, resulting in positioning accuracy of +/- .005″ per index. Optional long stroke shuttles
EAGLE BEAK VTR BLADE: 18’2″ long x 1.5″ wide blade, with 3/6 tooth pitch. Standard blade that is included with machine purchase
Round 0° (diameter): 20″
Round at 45° (diameter): 17″
Round at 60° (diameter): 11.25″
Rectangle at 0° (W x H): 20″ x 25″
Rectangle at 45° right (W x H): 20″ x 17″
Rectangle at 60° right (W x H): 20″ x 11.25″
Maximum vise opening: 20.25″
Work load capacity: 8,000 lbs
Blade size (L x T x W): 18’2″ x 0.050″ x 1-1/2″
Blade speed: 30-500ft/min by Inverter
Tension control: Hydraulic
Cutting control: Direct Force Sensing Electric Ball Screw with PC3 Programmable Control
Blade feed force: 0 to 300 lbs
Type: Main Vise (Optional second vise is available to install)
Control: Hydraulic, Full Stroking with 9-12″ High x 15″ Wide 60° Faceplates
Saw blade: 10 HP
Hydraulic pump: 5 HP
Cutting fluid pump: 1/8 HP
Tilt gear: 1/15 HP
Power supply voltage: AC230V +- 10% or AC460V +- 10%
3PH, 60 Hz, voltage must be specified when ordering
Tank capacity: 60 gal
Pump type: Electric
Tank capacity: 10 gal
Chip disposal: Manual
Machine dimensions (W x L x H): 94.7″ x 99.2″ x 90.8″
Table Height (Above Floor): 40″
Machine Weight: 2,867 lbs
