230/460/60/3 Electricals
Magnetic starter with 110V control circuit and overload protection
5 hp TEFC motor, with Brake (full stop from max. speed within 10 seconds, approximate)
Dual range transmission
Sets of (4) Chevron type blade guides, sizes 1/16”, 1/8”, 3/16”, ¼”, 3/8” , ½” , 5/8”, ¾” and 1” Back-up rollers in blade guide brackets
29 ½” W x 27 ½” L heavy duty cast iron table with two-way tilt (15°L & 15°R) solid table surface (V4014F)
29 ½” W x 27 ½” L heavy duty cast iron table with two-way tilt (15°L & 15°R) 4 T-slots on top hydraulic moving table. Table travel is 12.7”. Adjustable feed speed w/rapid retract (V4014H)
Auxiliary Table 19” W x 26 ¾” L
Bonded rubber band wheels
110V work light
Built-in air chip blower
Blade tension indicator
Blade speed indicator
Rip fence
1” carbon hardback blade
Locking band wheel doors
Operation and parts manual
2 year limited warranty
Throat: 40″
Table height: 54″
Work height (under guide): 14″
Drive motor: 5 Hp
Blade length: 262.5″ – 263″
Blade width: 1/8″ – 1.25″
Blade speed: 50-5200 (fpm)
Band wheel diameter: 40″ (2 wheel)
Table travel h-series: 13″
Length: 72″
Width: 41″
Height: 113″
Net weight F/H: 2,976/3,395 lbs.
Shipping weight F/H: 3,395/3,627 lbs.
