Double the throat distance of our Journeyman models
Adjusts-Blok® guides for 1/4″ to 3/4″ blade widths
Optional saw blade welder, grinder, and shear for longer saw blade life
Accurately control blade speed with the on-board digital inverter drive
Feed system: N/A
Blade travel: N/A
Cutting capacity at 90º: Round: 13″
Rectangle: 40″ x 13″
Miter cut angle range: 0º-45º (material can be rotated to 45º when cutting)
Bevel cut angle range: N/A
Clearance: 13″ table to guide
Throat: 40″
Blade size (ships with saw): 3/8″ width x 15′ 3″ length 10/14 variable tooth 0.035 thick (bi-metal)
Blade size (accepted widths): 1/4″, 3/8″, 1/2″, 5/8″ and 3/4″ (Adjusto-Bloke® guide roller works for each blade width)
Blade speeds: 70-500 sfpm (digital speed control)
Table: Precision ground steel table: 24″ x 50 1/4″
Table height: 39″ from floor (no casters)
Motor: 2 HP, 220/440V, three-phase
Saw dimensions: 76″ width x 30″ length x 80″ height
Shipping dimensions: 47″ width x 96″ length x 86″ height
Shipping weight: 1,050 lbs F.O.B. Cleveland, Ohio
