1.5hp drive motor, heavy-duty reducer, & 2 step drive assembly 3 phase machines single pulley for 1 phase machine
Swivel miter saw frame for adjustable left 0-60deg angles
Feed down cylinder
Motor with worm gear driven gear box, worm shaft is hardened and ground
Bi-metal saw blade
Blade tension gauge system
Coolant system
Machine stand with door
Operation & parts manual
Two (2) year limited warranty
Voltages are 220v/1ph and 230v/3ph all other voltages may require a transformer or special order
Type: Horizontal miter wet cut
Drive motor: 1.5 Hp
Blade (W x T x L): 1″ x 0.035″ x 96.5″
Blade speed (2 step pulley) MS9: 132/264 fpm
Blade speed (single pulley) MS9S1: 10-264 fpm
90º cutting capacity: Round 8.9″
Rectangular 9.45″ x 6″
+45º cutting capacity: Round 5.75″
Rectangular 5.75″ x 8.27″
+60º cutting capacity: Round 3.5″
Rectangular 3.5″ x 7″
Floor to table height: 39.5″
Floor space: 53″ x 28″ x 52.2″
Net weight: 550 lbs.
Shipping weight: 620 lbs.
Shipping dimensions: 60″ x 35″ x 60″
