Full or semi-automatic operation
Infinitely variable blade speeds
LED blade speed readout
Vise clamps work piece both sides of blade
Hydraulic down feed
Automatic height setting feature
Auto shutoff at end of material or after preset number of cuts
Front-mounted digital length gauge
Blade breakage/stoppage switch
110v. control circuit
Overload protection
Recirculating coolant system
Shuttle vise
Hydraulic blade tension system
(1) General purpose bi-metal blade
Flushing hose for cleanup
Tool kit
Operator’s manual
2 year limited warranty
Motor: 3 Hp, 230/460 3 Ph
Hydraulic pump motor: 1 Hp
Hydraulic oil capacity: 10.5 gallons
Band wheel dia.: 15.75″
Blade speeds: 66-328 fpm (variable speed)
Blade size (W x T x L): 1.25″ x 0.043″ x 138″
Coolant: Recirculating
Coolant capacity: 16.8 gallons
90º cutting capacity: Round 10″
Rectangular 10″ x 11″
Feed accuracy: +/- 0.004″ to 0.008″
Length of remnant material (manual): 0.59″
Length of remnant material (automatic): 1.97″
Minimum cut thickness: 0.354″
Bundle cutting width: 6.1″ x 7.87″
Bundle cutting height: 1.97″ to 4.72″
Feed length/index: 15.75″
Max. feed (9 times): 141.75″
Length: 74″
Width: 73″
Height down: 57″
Height (head-up): 62″
Bed height: 26″
Net weight: 2,660 lbs.
Shipping weight: 2,830 lbs.
