12″ x 10″ New Marvel Horizontal Scissor Style Band Saw Model PA10MPC Specifications:
12″ x 10″ New Marvel Horizontal Scissor Style Band Saw Model PA10MPC Features:
SPEED RANGE: 70-330 feet per minute (21-101 meters per minute) variable through a frequency inverter drive and heavy-duty worm gear transmission. The broad speed range allows for optimum cutting of a large spectrum of materials. A read out on the operator’s touch screen assures accurate speed setting.
BLADE GUIDE: The combination roller bearing and carbide blade guides reduce heat and blade stress providing longer blade life and accuracies of ±0.002 per inch (.051 mm) of cut material.
HYDRAULIC SHUTTLE FEED: Multi length shuttle indexing up to 999″. The shuttle comes to positive stops at both ends of the index, assuring cutoff length accuracy. Repeatability is ±0.005 per index. The shuttle vise jaw floats hydraulically to accommodate crooked stock assuring straight, accurate cuts.
HYDRAULIC DOWN FEED: Feed rate and down pressure can be controlled independently for fast, accurate cutting. Setup is made easy through the color-coded dial allowing the operator to select the optimum setting for the type of material being cut. Both settings are made at the operator’s station.
MPC PROGRAMMABLE CONTROL: Conveniently located on the operator’s control panel, this touch screen control allows the operator to program and store up to 100 jobs. Inputs include Part Length from 0 to 999” (0-25 m) (in inches up to 3 decimal places) and Number of Pieces to be cut. The Automatic Piece Counter stops each job when the pre-set number of cuts has been made. The control provides the option of running up to 20 parts in one job consecutively. MPC Control includes a material library for setting speeds and feeds.
FULL STROKING HYDRAULIC VISE JAWS: The front vise jaws are split to reduce the remnant to as little as 2.75” (70 mm). The split vise jaws also help to reduce burrs left on the material and are ideal for bundle cutting.
CHIP BRUSH: Powered from the main drive shaft of the saw, the brush changes speed along with the blade to ensure that chips are being removed from each gullet of the blade, improving cutting performance and blade life.
AUTOMATIC CHIP REMOVAL: The chip auger rotating in the coolant return removes chips quickly and efficiently, freeing the operator to perform more productive operations. Coolant is allowed to drain back to the tank before the chips are removed from the machine.
VARIABLE VISE PRESSURE: Hydraulic clamping pressure to the work holding jaws can be adjusted as required to hold solid or thin wall material, allowing the piece to be held securely and without distortion.
SGLB BLADE: These are the standard blades that are included with machine purchase.
SPLIT FRONT VISE
HMI TOUCH SCREEN CONTROL
AUTOMATIC CHIP REMOVAL
BI-DIRECTIONAL SHUTTLE VISE
FULL STROKING HYDRAULIC VISES
FULLY ADJUSTABLE HYDRAULIC DOWN FEED
AUTOMATIC HEIGHT SELECTION WITH FAST APPROACH
12″ x 10″ New Marvel Horizontal Scissor Style Band Saw Model PA10MPC Optional Features:
AUTOMATIC MIST LUBE
HYDRAULIC HOLD DOWNS
EXTENSION ROLLER TABLE
FIRST SECTION ROLLER TABLE
12″ x 10″ New Marvel Horizontal Scissor Style Band Saw Model PA10MPC Safety Features:
COVERED CHIP AUGER
COVER INTERLOCKS
STALLED OR BROKEN BLADE SENSOR
LOCKOUT TAGOUT CAPABLE
TWO HANDED FRONT VISE CLAMP OPERATION
SAFETY RAILING AROUND SHUTTLE
Rectangle (W x H): 11.8″ x 9.8″
Work Load Capacity: 5,600 lbs
Blade Size (L x T x W): 11’6″ x 0.42″ x 1-1/4″
Blade Speed: 65-330 ft./min by Inverter
Tension Control: Hydraulic
Top Limit Setting: Automatic Setting with Fast Approach Feeler
Cutting Control: Hydraulic Pressure & Flow Control Valve
Type: Front Split Vise and Rear Vise
Control: Hydraulic Full-Stroke Cylinder
Saw Blade: 5 HP
Hydraulic Pump: 1 HP
Cutting Fluid Pump: 1/4 HP
Power Supply Voltage: AC230V±10%, 3 PH, 60 Hz Required at Factory Voltage Setting
Tank Capacity: 21 gal
Tank Capacity: 13 gal
Pressure Setting: 569 psi
Chip Disposal: Chip Conveyor
Index Mechanism: Shuttle Vise
Head-Up Position: 89.1″ x 85.3″ x 70″
Head Down Position: 89.1″ x 85.3″ x 49.2″
Table Height: 28.5″
Machine Weight: 3,500 lbs
