0º-45º miter cutting, make angle cuts without swinging material to be cut
2 Hp main drive with magnetic starter and overload protection
Variable speed drive
230/460 60 cycle 3 phase electrics
Recirculating coolant system with application through both guides
Solid carbide blade guides with rollers
Quick position vise
Automatic shut-off at end of cut
Totally enclosed transmission
Blade cleaning brush
Cast iron bed
1” wide blade
Stock stop
Easily adjusted head feed with hydraulic power lift
Two (2) year limited warranty
Drive motor: 2 Hp, 230v or 460v, 3 ph
Hydraulic motor: 1/4 Hp
Coolant pump: 1/8 Hp
Band wheel diameter: 15.4″
Blade: 1″ x 0.035″ x 136.8″
Bed height: 21-3/4″
Vise opening: 18″
Blade speeds: 69-321 fpm (variable speed)
90º cutting capacity: Round 10″
Square 10″ x 10″
Rectangular 10″ x 16″
45º cutting capacity: Round 8″
Square 6″ x 6″
Rectangular 8″ x 6″
Width: 74.8″
Depth (with stock stop): 29.13″ (44.5″)
Height (head up): 64″
Height (head down): 39.37″
Net weight: 836 lbs.
Shipping weight: 990 lbs.
Shipping dimensions (L x W x H): 81″ x 36″ x 46″
