3” round, 11” x 11” square, 10.6” x 18” rectangular cutting capacity (90°)
4” round, 10.5” x 10.5” square, 10.5” x 10.5” rectangular cutting capacity (45°)
7” round, 8.7” x 8.7” square, 8.7” x 8.7” rectangular cutting capacity (30°)
3 HP motor, wt. 1,800 lbs
Coolant system
Auto saw arm return to preset height at end of cut to facilitate next cut.
4 step blade speeds with worm gear speed reducer operated with a toggle clamp device.
Carbide blade guides with roller bearings pre-align the blade before entering carbide blade guides. It enhances blade life.
Synchronized blade brush to remove chips from blade gullet
Adjuster stock stop
Manual blade tension adjustment
Easy blade change with front access at wait level
Adjustable mechanical material stop
Bi-Metal saw blade
Coolant system
Tools leveling pads and additional wire brush
Infinite variable speed device
2M roller table
1M roller table
Round: 0°: 13″
45°: 11.4″
60°: 8.7″
Square: 0°: 11″
45°: 10.5″
60°: 8.7″
Rectangular (H x W): 0°: 10.6″ x 18″
45°: 10.5″ x 10.5″
60°: 8.7″ x 8.7″
Speed: 75 ~ 247 fpm
Size: 163″ x 1.06″ x 0.035″
Tension: Spring Loaded
Cleaning: Wire Brush
Saw Blade: 2 HP
Hydraulic: 1/2 HP
Coolant: 1/8 HP
Vise Control: Full Stroke Cylinder Vise
Table Height: 32.3″
Net Weight: SW-130HTM: 1,320 lbs
SW-130HTSA: 1,408 lbs
Gross Weight: SW-130HTM: 1,760 lbs
SW-130HTSA: 1,848 lbs
Floor Space (L x W x H): 83″ x 65″ x 55″
