Semi-automatic operation
Infinitely variable blade speeds
LED blade speed readout
Vise clamps work piece both sides of blade
Powered hydraulic down feed
Automatic height setting feature
Auto shutoff at end of cut
Blade breakage/stoppage switch
Hydraulic blade tension system
110v. control circuit
Overload protection
2 year limited warranty
5 hp 230/460v. 3 ph. drive motor
Recirculating coolant system
(1) General purpose bi-metal blade
Stock stop assembly
1 gallon coolant
Tool kit
Operator’s manual
Flushing hose for cleanup
Motor: 5 Hp, 230/460V 3 Ph
Hydraulic pump motor: 1 Hp
Hydraulic oil capacity: 6.5 gallons
Band wheel dia.: 16″
Blade speeds: 85-445 fpm (variable speed)
Blade size (W x T x L): 1.25″ x 0.042″ x 150.4″
Coolant: Recirculating
Coolant capacity: 10 gallons
90º cutting capacity: Round 12.75″
Square 12.75″ x 12.6″
Rectangular 7.9″ x 14.2″
Bundle cutting width: 6.5″ x 10″
Bundle cutting height: 2″ to 8″
Length: 47″
Width: 75″
Height (head up): 73″
Height (head down): 61″
Bed height: 29.5″ (without pads)
Net weight: 2,039 lbs.
Shipping weight: 2,260 lbs.
