Full or semi-automatic operation
Infinitely variable blade speeds
LED blade speed readout
Vise clamps work piece both sides of blade
Hydraulic down feed
Automatic height setting feature
Auto shutoff at end of material or after preset number of cuts
Front-mounted digital length gauge
Blade breakage/stoppage switch
110v. control circuit
Overload protection
5 hp 230/460v. 3 ph. drive motor
Recirculating coolant system
Shuttle vise
Hydraulic blade tension system
(1) General purpose bi-metal blade
1 gallon coolant
Tool kit
Operator’s manual
Flushing hose for cleanup
2 year limited warranty
Motor: 5 Hp, 230/460v 3 Ph
Hydraulic pump motor: 1 Hp
Hydraulic oil capacity: 6.5 gallons
Band wheel dia.: 16″
Blade speeds: 95-395 fpm (variable speed)
Blade size (W x T x L): 1.25″ x 0.042″ x 150.4″
Coolant: Recirculating
Coolant capacity: 10 gallons
90º cutting capacity: Round 12.75″
Square 12.75″ x 12.6″
Rectangular 7.9″ x 14.2″
Feed accuracy: +/- 0.004″ to 0.008″
Length of remnant material (manual): 0.79″
Length of remnant material (automatic): 1.97″
Minimum cut thickness: 0.354″
Bundle cutting width: 6.5″ x 10″
Bundle cutting height: 2″ to 8″
Feed length/index: 15.75″
Max. feed (9 times): 141.75″
Length: 76.5″
Width: 76.5″
Height down: 57″
Height (head-up): 73″
Bed height: 26″
Net weight: 2,795 lbs.
Shipping weight: 2,945 lbs.
