Advanced hydraulic system provides dependable power for powered clamping and raising the saw head at end of cut
Full stroke machine vise for tight clamping of any material from operator’s panel
Swivel saw head allows the operator to accurately pivot head for angle cuts from 0º, for a 90º cut, to 60º
Carbide blade guides provide excellent stability for the saw blade
Variable blade speed, 98-328 fpm
Power chip brush removes chip from the blade extending blade life
Integrated coolant system
Cast iron moveable guide arms provide rigidity and stability for an accurate cut
Flushing hose
Adjustable work stop
Tool box with tools
Manual and parts list
Two (2) year limited warranty
Drive motor: 3 Hp, 230v or 460v, 3 ph
Hydraulic motor: 1/4 Hp
Hydraulic oil capacity: 2.1 gallon
Coolant motor: 1/8 Hp
Coolant capacity: 7.8 gallon
Blade speeds (inf. variable): 98-328 fpm
Blade size: 1″ x 0.035″ x 163″
Swivel angle range: 0º to 60º
Cutting capacity: Round @ 90º = 13″
Round @ 45º = 11.8″
Round @ 60º = 8.6″
Square @ 90º = 11″
Square @ 45º = 9.4″
Square @ 60º = 8.6″
Rectangle @ 90º = 11″ x 17.3″
Rectangle @ 45º = 11″ x 9.4″
Rectangle @ 60º = 11″ x 8.6″
Bed height: 32.3″
Length: 87.44″
Width: 43.38″
Height: 57.8″
Net weight: 1,408 lbs.
Shipping weight: 1,848 lbs.
