Swivel saw head allows the operator to accurately pivot head for angle cuts from 0º, for a 90º cut, to 60º
3 Hp drive motor with magnetic starter and overload protection
Manual vise clamping and raising the saw head at end of cut
Carbide blade guides provide excellent stability for the saw blade
Variable speed drive, 102-377 fpm
Chip brush removes chip from the blade extending blade life
Integrated coolant system
Cast iron moveable guide arms provide rigidity and stability for an accurate cut
Quick action vise
Flushing hose
Adjustable work stop
Tool box with tools
Manual and parts list
Two (2) year limited warranty
Drive motor: 3 Hp, 230v or 460v, 3 ph
Coolant motor: 1/8 Hp
Coolant capacity: 7.8 gallon
Blade speeds (inf. variable): 102-377 fpm
Blade size: 1″ x 0.035″ x 13′-7″
Swivel angle range: 0º to 60º
Cutting capacity: Round @ 90º = 13″
Round @ 45º = 11.5″
Round @ 60º = 8.7″
Square @ 90º = 10.6″
Square @ 45º = 10.5″
Square @ 60º = 8.7″
Rectangle @ 90º = 18.5″ x 10.6″
Rectangle @ 45º = 10.5″ x 10.5″
Rectangle @ 60º = 8.7″ x 8.7″
Bed height: 33″
Length: 75″
Width: 34″
Height: 55.5″
Net weight: 1,400 lbs.
Shipping weight: 1,850 lbs.
