Head Pressure Controlled By Hydraulic Cylinder
Sealed Oil Bath Worm Gear
Removable Chip Tray
Heavy Steel – Welded Base & Frame
Air Cooling System
Table Back Extension 7″
Maximum Cutting Capacity @ 45 Degrees: 13″ x 13″
Blade Speeds: 75 – 195 FPM Variable Speed
Main Motor: 2 H.P. 220 Volt 1 Phs.
Blade Size: 1-1/4″ x 15′ x .042″
Machine Weight: 1,250 Lbs.
