Linear guide way design for the saw frame movement
Cross link is located on the top of the pillars connecting them to form a gantry design for structural strength
First cut trim cut automatic function
Movement of guide arm is linked to the clamping vises
Rugged gearbox is designed to accept high lateral pressure, thus not creating thermal distortion
Heavy duty inverter blade drive system provides infinitely variable blade speed control from operators control station
Heavy duty cast guide arms effectivity absorb vibration and enhance cutting result
Automatic hydraulic blade tensioning device
Integral coolant system. Coolant is supplied at four critical points: exit and entry of blade through blade guides, middle of cut via adjustable flex hose, and blade cleaning brush
Split vise jaws for additional material support during the cutting process (full stroke)
Precision feed pressure & feed rate
Bundle/single cutting mode switch
Automatic height setting feature
Cast iron vises with replaceable hardened wear plates
Blade slippage or breakage detection
General purpose Bi-metal saw blade
Built in work light
Tool box, leveling pads and an additional wire brush, operation and parts manual
Two (2) year limited warranty
Standard voltage 230 volt 3phase all other voltages may require a transformer or special order
Touch panel entry of programmable quantity and length of cut with automatic shut-off for finished jobs or out of stock
Stored programs are easily recalled and executed
5.7” LCD screen with touch panel
Blade speed display
Blade life indicator
Feed vise position display
Automatic Kerf loss compensation
Automatic multiple indexing up to 99999mm (3,936”)
Save-A-Blade Feature – The shuttle vise will automatically retract the material slightly after the cut off, so a blade can avoid the undesirable abrasion with the material, improving blade life
Error code display provides simplified self-diagnostics
Main spindle: 7.5 Hp *230/3/60
Hydraulic pump motor: 2 Hp
Coolant pump: 1/8 Hp
Round: 14.2″ (360mm)
Square: 14.2″ x 14.2″ (360mm x 360mm)
Rectangular (H x W): 14.2″ x 15.7″ (360mm x 360mm)
Speed: 66-328 SFPM (20-100M/min)
Size: 192.1″ x 1.5″ x 0.051″ (4880x41x1.3mm)
Tension: Hydraulic controlled
Guides: Tungsten carbide blade guide
Cleaning: Powered driven wire brush
Hydraulic: 13.2 gal (50L)
Coolant: 23.7 gal (90L)
Mode: Hydraulic NC automatic controlled
Length single stroke: 19.7″ (500mm)
Length multiple maximum: 3,937″ (99999mm)
Vise Hydraulic: Full stroke
Bed Height: 31.1″ (790mm)
Net: 3,240 lbs (1472Kg)
Gross: 3,740 lbs (1700Kg)
Shipping (L x W x H): 95″ x 130″ x 80″ (2413x3300x2032mm)
Floor space (L x W x H): 82.7″ x 109″ x 70.8″ (2100x2770x1800mm)
