Twin column design ensures rigid support during cutting cycle by keeping the blade parallel and square to the work piece
Infinitely variable speed
Digital blade speed indicator
Carbide blade guides with roller bearings
Two additional guides to support the blade from the top
Automatic hydraulic blade tensioning
Power driven blade brushes
Integral coolant system
Automatic shutoff at end of material or after preset number of cuts
Precision feed pressure & feed rate
Cast iron vises with replaceable hardened wear plates
Discharge table with built-in coolant return
Blade slippage or breakage detection
Additional flushing hose
Bi-metal saw blade
Built in work light
Tool box, leveling pads and an additional wire brush
Operation and parts manual
Two (2) year limited warranty
Motor: 7.5 Hp, 230v 3 Ph
Hydraulic pump motor: 1 Hp
Hydraulic oil capacity: 13 gallons
Blade speeds (variable speed): 66-328 fpm
Blade size (W x T x L): 1.5″ x 0.05″ x 215″
Blade tension: Hydraulic
Coolant: Recirculating
Coolant capacity: 10.4 gallons
90º cutting capacity: Round 16.5″
Square 16.5″
Rectangular 13.8″ x 27.5″
Length: 47″
Width: 108″
Height: 84.2″
Bed height: 27.5″
Net weight: 4,440 lbs.
Shipping weight: 4,720 lbs.
