Twin column design ensures rigid support during cutting cycle by keeping the blade parallel and square to the work piece
Infinitely variable speed
Blade deviation detection
Digital blade speed indicator
Carbide blade guides with roller bearings
Two additional guides to support the blade from the top
Automatic hydraulic blade tensioning
Power driven blade brushes
Integral coolant system
LCD digital blade speed monitor
Precision feed pressure & feed rate
Cast iron vises with replaceable hardened wear plates
Discharge table with built-in coolant return
Blade slippage or breakage detection
Additional flushing hose
Bi-metal saw blade
Built in work light
Tool box, leveling pads and an additional wire brush
Operation and parts manual
Two (2) year limited warranty
Motor: 7.5 Hp, 230v 3 Ph
Hydraulic pump motor: 2 Hp
Hydraulic oil capacity: 10 gallons
Blade speeds (variable speed): 66-328 fpm
Blade size (W x T x L): 1.5″ x 0.05″ x 208.7″
Blade tension: Hydraulic
Coolant: Recirculating
Coolant capacity: 21.25 gallons
90º cutting capacity: Round 16.5″
Square 16.5″
Rectangular 16.5″ x 21.6″
Length: 109.7″
Width: 43.7″
Height: 72.6″
Bed height: 27.5″
Net weight: 4,188 lbs.
Shipping weight: 4,629 lbs.
