5.7” HMI touch screen controller
Swivel saw head mitering from 90° to +/- 45° to +/-60°
Rigid, oversized linear guides precision ground to ensure smooth hydraulically driven consistent feed rate of the cutting head
Guide arm travels along one linear guide and moves in sync with the full stroke hydraulic vise to always be at the best location possible when cutting
10 degree blade cant for longer blade life specific for structural steels
Fast and accurate mitering via automatic angle positioning through the HMI touch screen with 0.1° accuracy
Hydraulic angle lock-down device
Specially designed gearbox for smooth and powerful cutting
Heavy duty inverter blade drive system
Carbide blade guides
Two additional bearings for extra support of the blade
Automatic hydraulic blade tensioning device
Integral coolant system
Synchronized power driven blade brush
Adjustable control station at waist level
Infinitely variable blade speed control
Precision feed pressure & feed rate dual valve system
Proximity switch for sensing blade slippage or breakage
Electrical and hydraulic safety interlock
Conduits protection measure
“Alert Orange” safety measure
Blade “clip” device for easy blade change
Bi-metal saw blade
Tool box, leveling pads and an additional wire brush
Operation and parts manual
Two (2) year limited warranty
Voltage 230 volt 3 phase all other voltage will require special order or a transformer
Motor: 7.5 Hp, 230v 3 Ph
Hydraulic pump motor: 1 Hp
Hydraulic oil capacity: 9.1 gallons
Blade speeds (variable speed): 83-330 fpm
Blade size (W x T x L): 1.5″ x 0.050″ x 257.5″
Blade tension: Hydraulic
Coolant: Recirculating
Coolant capacity: 13 gallons
90º cutting capacity: Round 19″
Rectangular 16.5″ x 28″
45º cutting capacity: Round 16.5″
Rectangular 16.5″ x 17.7″
60º cutting capacity: Round 11.8″
Rectangular 16.5″ x 11.8″
Length: 130.3″
Width: 135.8″
Height: 88.6″
Bed height: 25.8″
Vise control: Full stroke hydraulic cylinder
Net weight: 6,100 lbs.
Shipping weight: 6,380 lbs.
