Oversized hydraulic cylinder
Hydraulic shuttle vice assembly
Inverter controlled infinitely variable speed
Carbide blade guides with roller bearings
Two additional guides to support the blade from the top
Automatic hydraulic blade tensioning
Power driven blade brushes
Integral coolant system
Smart NC-100 technology programmable up to 100 different jobs
Easy recall and execution of stored parts
Automatic shutoff after preset number of cuts or when out of stock
5.7” HMI touch screen incorporating readout on blade speed, blade life, feed vise position and error code display for self-diagnostics
Automatic kerf loss compensation & computer controlled multiple indexing
Precision feed pressure & feed rate
Bundle/single cutting mode switch
Automatic height setting feature
Hydraulic front and rear vises
Cast iron vises with replaceable hardened wear plates
Discharge table with built-in coolant return
Blade slippage or breakage detection
Adjustable cut-off stock fence
Additional flushing hose
Bi-metal saw blade
Built in work light
Tool box, leveling pads and an additional wire brush
Operation and parts manual
Two (2) year limited warranty
Motor: 7.5 Hp, 230v 3 Ph
Hydraulic pump motor: 2 Hp
Hydraulic oil capacity: 10.5 gallons
Blade speeds (variable speed): 66-328 fpm
Blade size (W x T x L): 2″ x 0.06″ x 238″
Blade tension: Hydraulic
Coolant: Recirculating
Coolant capacity: 22.5 gallons
90º cutting capacity: Round 20.5″
Square 20.5″
Rectangular 22″ x 20.5″
Bundle cutting width: 9.84″ x 18.5″
Bundle cutting height: 5.9″ x 12.4″
Feed length/index: 19.8″
Max. feed: 198″
Length: 125″
Width: 89″
Height: 89″
Bed height: 27.2″
Net weight: 6,930 lbs.
Shipping weight: 7,326 lbs.
