Planetary Gear Box reducer producing better efficiency then worm gear drives. Offers high transmission efficiency and stable blade tension.
Swivel saw head mitering from 90° to 60° left to 45° right
Rigid and heavy-duty pivot and trunion
Sturdy cast work table
24.4” solid discharge table with coolant return
Variable speeds from 66 thru 328 fpm using inverter drive
Carbide blade guides with roller bearings
Two additional bearings to support blade from the top
Cast iron guide arm supported by heavy-duty cast iron dovetail
Automatic hydraulic blade tensioning
Integral coolant system
Synchronized blade brush
Precision feed pressure & feed rate dual valve system
Conveniently designed control station
Electrical components located inside the control box with main lockout disconnect
Work height selector
Industrial rated hydraulic components
Full stroke machine vises
Breakage detector
Built-in adjustable material stop
Adjustable work light
Additional flushing hose
Bi-metal saw blade
Tool box, leveling pads and an additional wire brush
Operation and parts manual
Two (2) year limited warranty
Motor: 7.5 Hp, 230v 3 Ph
Hydraulic pump motor: 3 Hp
Hydraulic oil capacity: 22.1 gallons
Blade speeds (variable speed): 66-328 fpm
Blade size (W x T x L): 2″ x 0.050″ x 260″
Blade tension: Hydraulic
Coolant: Recirculating
Coolant capacity: 52 gallons
90º cutting capacity: Round 20″
Rectangular 16″ x 31″
45º cutting capacity: Round 17.7″
Rectangular 16″ x 21″
60º cutting capacity: Round 16″
Rectangular 16″ x 16″
Length: 166.5″
Width: 130″
Height: 107″
Feeding stroke: 59″
Multi feeding stroke: 650″
Bed height: 47.7″
Vise control: Full stroke cylinder
Floor space: 204.7″ x 139″ x 107″
Net weight: 17,417 lbs.
Shipping space: 203″ x 90″ x 99″
Shipping weight: 17,640 lbs.
