Oversized precision ground, large dual columns
Cross link connecting two columns for enhanced structural strength
Specially designed gearbox for high lateral pressure
Heavy duty inverter blade drive system
LED speed indicator
Cam lock carbide blade guides with bearing guides
Two additional guides to support the blade from the top
Automatic hydraulic blade tensioning device
Integral coolant system
Synchronized power driven blade brush
Smart NC-20 Control
Ergonomically located independent control station
Precision feed pressure & feed rate dual valve system
“Last cut” or “keep on” selector
Split vise jaws
Full stroke ductile cast iron split vise
NC Controlled multiple indexing for long cutting lengths up to 650”
Ductile cast iron vises with replaceable hardened wear plates
Proximity switch for sensing blade slippage or breakage
Blade “clip” device for easy blade change
Discharge roller workbed with built-in coolant return
Additional flushing hose
Bi-metal saw blade
Tool box, leveling pads and an additional wire brush
Operation and parts manual
Two (2) year limited warranty
Motor: 10 Hp, 230v 3 Ph
Hydraulic pump motor: 2 Hp
Hydraulic oil capacity: 10.5 gallons
Blade speeds (variable speed): 66-328 fpm
Blade size (W x T x L): 2″ x 0.06″ x 283″
Blade tension: Hydraulic
Coolant: Recirculating
Coolant capacity: 22.5 gallons
90º cutting capacity: Round 24.4″
Square 24.4″ x 24.4″
Rectangular 24.4″ x 30″
Bundle cutting width: 27.5″ max
Bundle cutting height: 15.3″ max
Feed length/index: 19.7″
Max. feed: 999″
Length: 160.5″
Width: 82.4″
Height: 94.1″
Bed height: 23.6″
Net weight: 10,582 lbs.
Shipping weight: 11,904 lbs.
