Swivel saw head mitering from 90° to 60°
Precision ground, oversized round column design
7.5 degree blade cant for longer blade life
Heavy duty, rigid saw frame supported by two large bore hydraulic cylinders
Cross link connecting the two columns for enhanced structural strength
45 degree forward and backward swivel with automatic angle lock-in
Specially designed gearbox for smooth and powerful cutting
Heavy duty inverter blade drive system
Easy to read LED speed indicator
Hydraulically operated carbide blade guides
Two additional bearings for extra support of the blade
Automatic hydraulic blade tensioning device
Hydraulically actuated guide arm
Integral coolant system
Synchronized power driven blade brush
Independent control station
Precision feed pressure & feed rate dual valve system
“Last cut” or “keep on” selector switch
Vise pressure detector
Hydraulically powered material infeed lift roller
Idle roller work table for material feeding
Light projection for precise length measurement
Two full stroke cylinder vises
Proximity switch for sensing blade slippage or breakage
Electrical and hydraulic safety interlock
Conduits protection
Bi-metal saw blade
Tool box, leveling pads and an additional wire brush
Operation and parts manual
Two (2) year limited warranty
Motor: 10 Hp, 230v 3 Ph
Hydraulic pump motor: 3 Hp
Hydraulic oil capacity: 15.6 gallons
Blade speeds (variable speed): 49-295 fpm
Blade size (W x T x L): 2″ x 0.063″ x 326.8″
Blade tension: Hydraulic
Coolant: Recirculating
Coolant capacity: 26 gallons
90º cutting capacity: Round 26″
Rectangular 20.5″ x 40″
45º cutting capacity: Round 23″
Rectangular 20.5″ x 24.4″
60º cutting capacity: Round 15.7″
Rectangular 21.3″ x 15.7″
Length: 148″
Width: 154″
Height: 109″
Bed height: 31.9″
Net weight: 9,460 lbs.
Shipping weight: 12,254 lbs.
