The extra heavy-duty saw frame is supported by two large bore hydraulic cylinders, providing unsurpassed rigidity and the smoothest cutting possible
Dual column design with precision ground columns ensures smooth saw frame movement and consistent cutting force throughout the cutting cycle
Large diameter cast iron bandwheels
Inverter drive with infinitely variable blade speeds with blade speed indicator
Hydraulic controlled tungsten carbide blade guide
Groove shaped designed blade guides
Hydraulic controlled blade tension device
Hydraulic driven guide arm
Proximity switch for sensing blade slippage or breakage
Independent wire brush drive system
Auto shut-off function automatically stops the machine and shuts down the hydraulic system at the end of the last cut
Two full stroke cylinder vices
Discharge table with built-in coolant return
Heavy-duty machine structure design for heavy cutting jobs
Precise flow control valve to finely adjust the cutting speed
Additional flushing hose
Bi-metal saw blade
Tool box, leveling pads and an additional wire brush
Operation and parts manual
Two (2) year limited warranty
Motor: 15 Hp, 230v 3 Ph
Hydraulic pump motor: 3 Hp
Hydraulic oil capacity: 26 gallons
Blade speeds (variable speed): 49-264 fpm
Blade size (W x T x L): 2.5″ x 0.063″ x 346.5″
Blade tension: Hydraulic
Coolant: Recirculating
Coolant capacity: 32 gallons
90º cutting capacity: Round 31.5″
Square 31.5″
Rectangular 31.5″ x 39.4″
Length: 90″
Width: 169″
Height: 105″
Bed height: 25.2″
Net weight: 22,000 lbs.
Shipping weight: 23,320 lbs.
