Numerical Control System (Mitsubishi Control)
Inverter for infinitely blade speed control. (Available for voltage under 460v)
Hydraulic double action vise (double retracting type)
Wire brush with drive shaft driven by separate brush motor
Hydraulic shuttle vise with automatic indexing feed
Automatic work height and quick approach control system
Multiple indexing control
Pre-set cut-off piece counter with automatic power shut-off function
Adjustable guide plate for cut-off piece
Additional coolant nozzle for cutting large section piece
Beam light
Flushing hose for wire brush and machine cleaning
Vise clamping indicator and out of stock sensor
Idle wheel motion detector
Self-lubricating carbide blade guide and guide roller
Selector for shuttle vise positioning of bundle or single stock cutting
Precision pressure and feed rate dual valve
Integral coolant system
Chip conveyor
Load meter
Work height detector
Blade clipping device for one operator changing of blade
Rigid frame type with gauge meter and guide arm support
Independent control station
One piece of Bi-Metal M42 saw blade
Tools with toolbox
Operation manual and parts book
Round: 39.4″
Square: 39.4″ x 39.4″
Minimum Clamping Width: 11.2″
Speed: 15-80 m/min (60 HZ) (50-264 ft/min)
Size: 370″ x 2.64″ x 0.06″
Tension: Hydraulic controlled
Guide: Tungsten carbide blade guide (hydraulic clamping force)
Arm: Hydraulic controlled
Cleaning: Wire brush with flexible drive shaft driven by brush motor
Saw blade: 15 Hp 230v 3ph
Hydraulic: 3 Hp
Coolant: 1/4 Hp
Hydraulic oil: 100L
Coolant: 120L
Mode: Hydraulic automatic, SNC programmable, 20 steps
Single stroke: 19.7″
Multi stroke: 256″
Rest Piece: 15.75″
Kerf Compensation: Automatic
Vise Control Method: Hydraulic full stroke cylinder
Net weight: 24,255 lbs.
Workbed height: 24.4″
Floor space (L x W x H): 86.6″ x 183.7″ x 138.6″ (without roller table)
