The extra heavy-duty saw frame is supported by two large bore hydraulic cylinders, providing unsurpassed rigidity and the smoothest cutting possible
Dual column design with precision ground columns ensures smooth saw frame movement and consistent cutting force throughout the cutting cycle
Specially designed planetary gear reducer for optimum mechanical efficiency
Inverter controlled infinitely variable blade speed with blade speed indicator
Hydraulically powered guide arm is position from the control panel
Hydraulic Blade Tension System with easy to read pressure gauge
Carbide blade guides are activated hydraulically
Additional blade guiding bearings for extra support
Heavy cast iron moveable guide arm is hydraulically powered from the control panel
Auto shut off function
User-friendly control panel
Precision feed pressure control valve with micro-precision adjustment
Saw blade height selector
Hydraulic driven work bed with rollers for moving large material safely
Three sets of vises designs. The front and middle vises hold the stock during cutting while the guide vise can be separately controlled to guide the material during feeding cycle
Stock position cylinder pushes stock away from fixed vise for easy material handling
Shadow light for material measurement
Blade breakage and/or slippage detector
Bi-metal saw blade
Tool box, leveling pads and an additional wire brush
Operation and parts manual
Two (2) year limited warranty
Motor: 20 Hp, 230v 3 Ph
Hydraulic pump motor: 3 Hp
Hydraulic oil capacity: 35 gallons
Blade speeds (variable speed): 49-264 fpm
Blade size (W x T x L): 3″ x 0.063″ x 512″
Blade tension: Hydraulic
Coolant: Recirculating
Coolant capacity: 44 gallons
90º cutting capacity: Round 51″
Square 51″
Rectangular 51″ x 67″
Length: 118″
Width: 232″
Height: 166.5″
Bed height: 24.4″
Net weight: 48,500 lbs.
Shipping weight: 51,410 lbs.
