Universal gear box
Oil gauge for indicating lube pump
18 spindle speed selecting levers
6″~21″ bore spindle is selectable by customer
Compact lay-out electric cabinet
A 1-1/5″ to 13-4/5″ steady rest
Indexable four way tool post
Forward/Reverse selection lever
Auto/manual tool post selection knob
Followable splash guard
Tailstock connecting device
Saddle lock device
Halogen light
Automatic movable screw support
Telescopic taper turning attachment
Followable cable cover
Internal triangular rib for heavy cutting support
Quick clamp action lever
One piece bed and base casting
Two speed selection lever
Spindle center run-out
Cam action of spindle
Spindle taper run-out
Headstock alignment
Saddle way alignment
Cross slide alignment
Open steady rest, 1.8 in. – 15.75 in.
Open steady rest, 13.8 in. – 27.56 in.
Closed steady rest, 1.5 in – 15.75 in.
Closed steady rest, 13.8 in. – 27.56 in.
Follower rest
Hydraulic steady rest
Spindle oil cooler
Boring bar support size small
Boring bar support size large
VDI tool holding
Live tool holders
Spindle indexing
Special milling attachment
Special grinding attachment
Center Height: 23-3/4″
Swing Over Bed: 70-1/2″
Swing Over Gap: 90-1/2″
Swing Over Cross Slide: 57-3/8″
Center Distance: 60″~800″
Spindle Nose: A2-28
Spindle Bore: 21″
Spindle Speeds: 1.5~180
Taper of Center: MT. #6
Cross Slide Travel: 31-1/2″
Compound Rest Travel: 15-3/4″
Max. Size Cutting Tool: 1-3/5″ x 2-3/4″
Spindle Diameter: 5-3/4″
Bearing Surface on Ways: 23-5/8″
Tailstock Taper: MT. #6
Bed Length: 100″ ~ 829″
Bed Width: 28″
Width of Gap: 17-3/4″
Threading: inch/metric
Pitch of Leadscrew: 50 Ø, 2 TPI
Metric Pitch Threads: 1~56 mm (60)
Inch Pitch Threads: 2/1 (2 in. per thread) ~ 28 TPI (60)
Module Pitch Threads: M.P.O. 25~14 (60)
Diametral Pitch Threads: D.P.O. 2~112 (60)
Longitudinal Feeds: 0.0018 ~ 0.1 IPR
Cross Feeds: 0.01 ~ 0.05 IPR
Main Drive Motor: 40/50 HP
Rapid Traverse Motor: 2 HP at 80″ ~ 40″/min
Coolant Pump Motor: 1/8 HP
Floor Dimension: 147″~876″ x 130″
Machine Net Weight: 34500 lbs
Machine Gross Weight: 36700 lbs
Packing Dimension: 151″~890″ x 91″ x 91″
SKU: 20631
