New Kent USA Vertical Machining Center KQVM-610AII

The KENT CNC KQVM-610AII Vertical Machining Center is designed for high-speed, high-precision machining with significant improvements over its predecessor. The machine structure has been optimized using Finite Element Analysis (FEA) to ensure greater rigidity and stability during high-speed operations. A triple-point clamping and support system enhances pallet stability and surface finish quality. The Z-axis stroke has been increased by 1.97″ (50 mm) to accommodate larger workpieces and 4th-axis applications, while the use of high-quality components, such as a high-rigidity spindle and German-made linear guideways, ensures long-term durability and consistent performance.
The KQVM-610AII also features an upgraded APC (Automatic Pallet Changer) system powered by an electric motor rather than a hydraulic system, making it more energy-efficient and easier to maintain. Its roller gear mechanism reduces required torque and improves launch smoothness. Table loading capacity has doubled to 880 lbs (400 kg) x2, allowing for heavier workpieces. The ATC (Automatic Tool Changer) has been redesigned with a faster angular encoder system, a new deceleration ratio (from 1:10 to 1:7), and a higher-output motor, cutting tool change time from 3 seconds to just 1.6 seconds. Rigidity across the X, Y, and Z axes has been increased by more than 50%, contributing to superior machining stability. Additional thoughtful design features—like a raised concealed pedal, collection cabinet, and ease of daily maintenance—make the KQVM-610AII a highly efficient and user-friendly vertical machining solution.
X/Y/Z-Axis Travel: 24.0″ / 16.1″ / 20.1″ (610 mm / 410 mm / 510 mm)
X/Y/Z-Axis Travel: 24.0″ / 16.1″ / 20.1″ (610 mm / 410 mm / 510 mm)
X/Y/Z-Axis Rapid Traverse: 1,417 in/min (36 m/min) | 1,417 in/min (36 m/min) | 1,181 in/min (30 m/min)
X/Y/Z-Axis Rapid Traverse: 1,417 in/min (36 m/min) | 1,417 in/min (36 m/min) | 1,181 in/min (30 m/min)
Spindle Speed: 8,000 rpm (Opt. 10,000 rpm)
Spindle Speed: 8,000 rpm (Opt. 10,000 rpm)
Chip conveyor tank
Separated manual pulser
Inner workpiece counter
Tri-colors warning light
Tool magazine
Machine bed flushing system
Spindle taper air blow
Door security switch
Spindle external cooling
Disc-type oil skimmer
Air gun
Coolant gun
Automatic door
Oil-mist collector
Oil-pressure device and interface
Spindle cooling device
Tool breakage/measurement
Standard 4th axis
A/C for electrical cabinet
CE marking
Automatic power-off system
Transformer/ Stabilizer
Coolant through spindle (C.T.S.)
About Us
Worldwide Machine Tool is the leader in providing full sales, parts and service, financing, transportation and training of new and used machine tools for chip and fabrication clients across the United States, Canada and Mexico. Our warehouses and office is located just minutes north of Columbus, Ohio. With over 28 years of experience in the industrial machine tool industry, we have the knowledge and expertise to provide our customers with the best customer service, support and technical expertise on all new and used machine tools to meet their needs.
We buy and sell new and used ironworkers, shears, lathes, milling machines, drills, saws, press brakes, routers, turret punch models, presses, welders, deburring and beveling machines, plate rolls, laser, waterjets and associated tooling and accessories. We take pride in being a trustworthy partner that our customers rely on through the years. Our experienced sales team would love to help you with your next machine tool purchase. Give us a call today or Request A Quote. Call 614-255-9000 or Contact us today to experience the Worldwide Machine Tool difference.
Check us out on Twitter, Facebook, Youtube, and Instagram.
Worldwide Machine Tool LLC.

Terms and Conditions: https://www.worldwidemachinetool.com/terms-conditions/

Table Size (LxW): 27.56″ x 16.14″ (700mm x 410mm)
Table Max. Loading Capacity: 881.8 lbs (400 kg)
Table height from floor: 37.4″ (950mm)
T-slot (sizexNo.): M16 x 2.60″ (66mm) (PIN x8)
Spindle Taper: 7/24 Taper No.40
Spindle Speed: 8,000 rpm (Opt. 10,000 rpm)
X/Y/Z axis travel: 24.02″ / 16.14″ / 20.08″ (610mm / 410mm / 510mm)
Distance from table surface to spindle gage line: 7.09″ ~ 27.17″ (180mm ~ 690mm)
X/Y/Z axis rapid traverse: 1,417 ipm / 1,417 ipm / 1,181 ipm (36m/min | 36m/min | 30m/min)
Cutting feedrate: 0.04–393.7 ipm (1~10,000 mm/min)
Tool Shank: BT-40
Tool Capacity: 24 pc (Opt. 30 pc)
Max. tool diameter: Ø3.5″ (Ø89mm)
Max. tool diameter (w/o adjacent tool): Ø5.31″ (Ø135mm)
Max. tool length: 9.84″ (250mm)
Max. tool weight: 15.43 lbs (7 kg)
Spindle Motor: 10 HP / 7.4 HP (Opt. 12 HP / 10 HP) (7.5 / 5.5 kW; Opt. 9/7.5 kW)
X/Y/Z axis servo motor: 4.0 / 4.0 / 5.4 HP (3.0 / 3.0 / 4.0 kW)
Machine Dimensions (WxDxH): 96.06″ x 181.50″ x 113.39″ (2440mm x 4610mm x 2880mm)
Machine Weight: 16,534 lbs (7500 kg)
Controller: FANUC Oi-MF
