3 HP motor with fan cooling system dissipates heat efficiently
Grease fitting for lubricating the bull gear
One piece quill pinion & shaft
Precision hand scraped contact surfaces between turret and column
X, Y & knee axes hardened & ground to HRC 52
Top brand “FUJI” or equivalent A.C. frequency inverter drive
Hardened & ground table top to HRC 52
Licensed “MEEHANITE” casting
3 HP variable speed from 60 to 4,500 RPM
Dish-in coolant base
Extra oiler lubricates the high-low moving device
Extra oiler to lubricate the quill
Precision ground ram ways within 0.0004″ accuracy
Precision ground finished lead screws
Precision ground table guide line to 0.0002″ over 20″
Standard accordian type way cover
Turcite-B coated saddle ways
About Us
Worldwide Machine Tool is the leader in providing full sales, parts and service, financing, transportation and training of new and used machine tools for chip and fabrication clients across the United States, Canada and Mexico. Our warehouses and office is located just minutes north of Columbus, Ohio. With over 28 years of experience in the industrial machine tool industry, we have the knowledge and expertise to provide our customers with the best customer service, support and technical expertise on all new and used machine tools to meet their needs.
We buy and sell new and used ironworkers, shears, lathes, milling machines, drills, saws, press brakes, routers, turret punch models, presses, welders, deburring and beveling machines, plate rolls, laser, waterjets and associated tooling and accessories. We take pride in being a trustworthy partner that our customers rely on through the years. Our experienced sales team would love to help you with your next machine tool purchase. Give us a call today or Request A Quote. Call 614-255-9000 or Contact us today to experience the Worldwide Machine Tool difference.
Check us out on Twitter, Facebook, Youtube, and Instagram.
Worldwide Machine Tool LLC.
Terms and Conditions: https://www.worldwidemachinetool.com/terms-conditions/
Working Surface: 10″ x 50″ (10″ x 54″ Optional)
Travel (X-axis): 32.5″ (36.5″)
Travel (Y-axis): 17″
Travel (Z-axis): 19″
Ram Travel: 20″
T-Slot Number, Size: 3, 5/8″
Main Motor: 3HP
Head Rotates Right-Left: ±90
Head Tilts Front-Back: ±45
Spindle Drive: Variable
Spindle Speed: 60 ~ 4,500
Spindle Taper: R-8
Power Quill Feeds (In/Rev): 0.0015″ , 0.003″ , 0.006″
Quill Diameter Chromed: 3.375″
Quill Travel: 5″
Net Weight: 3,300 lbs (3,450 lbs)
