NEW BRIDGEPORT KTM-VH300EVS

Turret type inverter / variable speed head
5 HP horizontal spindle motor, 6 speed ranges. 5 HP vertical spindle motor, 50″ x 14.6” hardened and ground table top
Saddle and knee with hardened and ground square (box) ways
Precision ballscrews in X & Y axes
X & Y axes driven by AC servo motor
Precision boring and ground milling head, with super precision ABEC-7 bearings
Meehanite® casting, with built in coolant reservoir in machine base
Coolant system and chip tray
Centralized automatic lubrication, with metered check-valves
Coolant System
X, Y Axes Servo Motor
X, Y Axes Ball Screw
Vertical Head Auto Lubrication Pump
Slideway Auto Lubrication Pump
Y-Axis Inverter Movement with Ball Screw
X-Axis Ball Screw with Inverter Movement
Vertical Head Attachment
Turret Head Inverter Motor with Controller
Air Power Drawbar
Table Size Opt. 57.9″ x 14.6″

About Us
Worldwide Machine Tool is the leader in providing full sales, parts and service, financing, transportation and training of new and used machine tools for chip and fabrication clients across the United States, Canada and Mexico. Our warehouses and office is located just minutes north of Columbus, Ohio. With over 28 years of experience in the industrial machine tool industry, we have the knowledge and expertise to provide our customers with the best customer service, support and technical expertise on all new and used machine tools to meet their needs.
We buy and sell new and used ironworkers, shears, lathes, milling machines, drills, saws, press brakes, routers, turret punch models, presses, welders, deburring and beveling machines, plate rolls, laser, waterjets and associated tooling and accessories. We take pride in being a trustworthy partner that our customers rely on through the years. Our experienced sales team would love to help you with your next machine tool purchase. Give us a call today or Request A Quote. Call 614-255-9000 or Contact us today to experience the Worldwide Machine Tool difference.
Check us out on Twitter, Facebook, Youtube, and Instagram.
Worldwide Machine Tool LLC.

Terms and Conditions: https://www.worldwidemachinetool.com/terms-conditions/

Table size: 11.8″ x 50″
Table Travel (X Axis): Manual 36.6″ / Auto 36.2″
Saddle Travel (Y Axis): Manual 15.7″ / Auto 14.96″
Knee Travel (Z Axis): Manual 17.7″ / Auto 16.5″
T-Slot: 16 x 3 x 80
Feed (Long) / min: 0.97″~12.6″ (6 Steps)
Feed (Cross) / min: 40.9″
Vertical / min: 14.17″
Steps: Variable
Spindle Speed RPM: 75~3166
Swiveling Angle: 45° (R&L)
Quill Travel: 5.51″
Quill Feeds/Rew: 0.0014″ / 0.0028″ / 0.0055″
Spindle Nose to Table: 3.7″ ~ 21.4″
Spindle Center to Column Face: 7.5″ ~ 27″
Cross Journey of Ram: 19.69″
H. Spindle Nose: N.S.T. 40
H. Spindle Speed RPM: 60 ~1440
H. Steps: 9
H. Spindle to Bottom of Ram: 6.89″
H. Spindle Center to Table Top: 0″ ~ 17.7″
V. Spindle Motor: 5 HP / 4P Inv.
H. Spindle Motor: 5 HP / 4P
X,Y Axis Feed: 3/4 HP / 4P, 1/2 HP / 4P – 1/5
Z Axis Feed: 1/2 HP – 4P – 1/10
Coolant Pump: 1/8 HP / 2P
Dimensions (LxWxH): 68.5″ x 63.5″ x 79″
Net Weight: 5401 lbs
