6' x 12' 6kW CNC Laser
| Sheet-W | 60" | 1,524 mm |
| Sheet-L | 120" | 3,048 mm |
| Wattage | 6000 w | 6,000 W |
| X | 168" | 4,267.2 mm |
| Y | 81" | 2,057.4 mm |
| Z | 3.94" | 100.08 mm |
Request a Quote
Add to Cart
Table Width: 6'
Table Length: 12'
Max Wattage: 6,000
Control: Amada Control
X-Axis Travel: 168"
Y-Axis Travel: 81"
Z-Axis Travel: 3.94"
Maximum Axis Positioning Speed: 4,724 IPM
HS-2007 Anti-Plasma Noise Resistant Z-Axis Sensor: Amada EZ Cut System Included (Nitrogen)
Automatic 4 Ports With NC Pressure Control: Cartridge Type Cutting Head
Chiller Unit: Cut Process Monitoring
Dual Pallet Shuttle Tables: Dust Collector
Fanuc AC Servo Motors: High-Speed Low Maintenance Linear Drives On All Axes
MDI and Manual Automatic Operating Modes: NC Focus and Assist Gas
Nozzle Cleaner: Oil Shot
Stationary Table/ Flying Optic Travel Method: Twin Adaptive Optics
