| Type | Hydraulic | Hydraulic |
| Clamping Force Tonnage | 650 T | 589.671 t |
| Barrel Code | 60S | 60S |
| Shot Volume (PS) | 91.7 oz | 2,599.1 g |
| Screw Diameter | 3.622" | 91.999 mm |
| Maximum Injection Pressure | 22188 psi | |
| Maximum Holding Pressure | 22188 psi | |
| Tie Bar Distance H | 37.4" | 949.96 mm |
| Tie Bar Distance V | 37.4" | 949.96 mm |
| Platen Dimension H | 53.94" | 1,370.1 mm |
| Platen Dimension V | 53.94" | 1,370.1 mm |
| Clamp Stroke | 37.4" | 949.96 mm |
| Maximum Daylight | 76.77" | 1,950 mm |
| Mold Height Min | 17.72" | 450.09 mm |
| Mold Height Max | 39.37" | 1,000 mm |
| Ejector Stroke | 7.09" | 180.09 mm |
| Control | CNC (syscom 1000) | CNC (syscom 1000) |
Barrel Type N-Aloy 60S
Hot Runner Manifold Zones :8
Hot Runner Nozzle Zones :4
Hydraulic Valve Gate : 2
Fixed Side Hydraulic Corepulls :1
Moving Side Hydraulic Corepulls :1
