| Clamping Force Tonnage | 850 T | 771.108 t |
| Barrel Code | N-Aloy N2000F | N-Aloy N2000F |
| Shot Volume (PS) | 117.2 oz | 3,323.7 g |
| Screw Diameter | 3.937" | 100 mm |
| Maximum Injection Pressure | 22625 psi | |
| Maximum Holding Pressure | 20305 psi | |
| Screw Torque High Speed | 165 | 165 |
| Tie Bar Distance H | 51.97" | 1,320 mm |
| Tie Bar Distance V | 51.97" | 1,320 mm |
| Platen Dimension H | 74.8" | 1,899.9 mm |
| Platen Dimension V | 70.87" | 1,800.1 mm |
| Clamp Stroke | 47.24" | 1,199.9 mm |
| Maximum Daylight | 90.55" | 2,300 mm |
| Mold Height Min | 19.69" | 500.13 mm |
| Mold Height Max | 43.31" | 1,100.1 mm |
| Ejector Stroke | 7.87" | 199.9 mm |
| Power supply Volts | 230 | 230 |
| Machine under power | Under power running with mould | Under power running with mould |
| Control | CNC (SYSCOM 3000) | CNC (SYSCOM 3000) |
Barrel code: N-Aloy N2000F
Screw type: LSP-2,M3
Hot runner manifold Zones: 8
Hot runner Nozle zones: 4
Hydraulic Valve Gate : 4
Fixed Side Hydraulic Corepulls: 1
Moving Side Hydra ulic Corepulls: 1
2014 Star Robot TW-1800VI-480
2014 Star Robot TW-800VI-480
