USED 2015 OKUMA MULTUS U4000 2SW/2000

High Pressure Coolant System (1000 PSI)| Lower Turret| Sub Spindle
Used Okuma MULTUS U4000 2SW/2000 B-Axis CNC Lathe (2015) with Okuma OSP-P300S Control. This machine is engineered for high-precision machining in the oil & gas and aerospace sectors. It handles complex, multi-operation parts in a single setup with its high torque and big bore capacity. Ideal for oilfield components like valve bodies, downhole tools, and long shaft work, as well as aerospace components such as landing gear and aircraft parts. Ideal for manufacturers seeking top performance and reliability!

Control: Okuma OSP-P300S
Spindle Nose: A2-11
Maximum Speed: 3,000 RPM
spindle power: 22 HP (continuous) / 43 HP (30-minute)
Spindle Bore (Big Bore): 4.41″
Sub-Spindle: A2-8
Maximum Turning Diameter: 25.6″
Maximum Turning Length: 78.7″
B-axis range: -30° to +210°
Milling Spindle Speed: 12,000 RPM
Axis Configuration: 8-Axis / Simultaneous 5-Axis Machining
AUTOMATIC TOOL CHANGER: 80 Tools – Capto C6
Machine Construction: Heavy-duty box-way design for high-torque cutting

Big Bore A2-11 Main Spindle
5-Axis Machining Package
NC B-Axis Contouring
C-Axis Synchronization
Lower Turret Milling Function
Negative Tool Radius Compensation
Lathe Tool Indexing – Multi-Edge
Z-Axis Auto Zero Offset
C-Axis Auto Zero Offset
Hydraulic Oil Temperature Regulator
Rapid Traverse Override Switch
80-Station ATC – Capto C6
Touchsetter
JF Berns Loader
ChipBlaster High-Pressure Coolant System
Chip Conveyor
Y-Axis Gauging
Optional Filter Starter Kit
MistBlaster Constant System
Big Bore Drawtube
