NEW MARVEL MANUFACTURING PS 1628/10/15/20

Marvel Spartan 16" x 28" Vertical Plate Saw, Model PS 1628/10/15/20 - NEW
SKU # 2322001
SPARTAN MODEL PS-1628/10 VERTICAL MOVING HEAD PLATE SAW WITH 2 INCH BLADE

Capacity:  16" (400 mm) Height x 28" (700 mm) Width x 118" (3 meters) Length
Blade:  2" (54 mm) x .063" (1.6 mm) x 20'-4" (6200 mm)
Support Table Width:  Inner Table        27.5" (700 mm)
Outer Table       63" (1600 mm)
Speed Range:  65-325 fpm (20-100 m/min.) infinitely variable, driven by heavy-duty worm gear transmission and variable  speed pulley.
Feed Rate:  .080-20"/m (2-500 mm/min.)
Motors:            Blade Drive                   7.5 H.P.
Feed Drive                       1 H.P.
Hydraulic Pump                2 H.P.
Coolant Pump                   1 H.P.
Automatic Chip Removal:  The chip auger rotating in the coolant return removes chips quickly and efficiently, freeing the operator to perform more productive operations.
Table Height:  53.125" (1350 mm)
Overall Dimensions:  31' 2" (9500 mm) Long x 8'10" (2700 mm) Wide, with 6 meter table.
Machine Height:  10' 2" (3100 mm)
Machine Weight:  Approximately 22,000 lbs. (10,000 kg) (20' model)
STANDARD FEATURES

Space Saving Moveable Saw Head

Precision Linear Ways

Hydraulically Positioned Saw Guide Arm

Hydraulic Blade Tension

AC Servo Feed

Programmable Feed and Blade Speed Settings

Rapid Approach and Return of Saw Head

Motion Detector

Automatic Feed Adjustment

On-Screen Self Diagnostics

Out-of-Square Detector

Powered Chip Brush

Priced with an 118" Table, Available with 177" or 236" Table
