Ercolina 2″ Manual Angle Roll, Model CE35 – NEW
Ercolina’s CE60H3 angle roll offers hydraulic center roll positioning.
Key Features:
50mm roll shaft diameter
Maximum pipe capacity 3″ Sch. 10
Maximum angle capacity 2-1/2″ x 2-1/2″ x 3/8″
Bending speeds 20% faster than competitive machines
Universal tooling set included with each machine – 7″ OD
Use same tooling as CE50
Forged roll shafts precision ground and fitted for maximum performance and minimal deflection
Heavy duty structure and rigid components for high section modulus ratings
Reinforced engineered mainframe design proven to outperform competitive models
Patented by Ercolina simultaneous down feed and roll movement to minimize deformation
Touchpad controls with digital center roll positioning display
Tie bar supports for each shaft
Memory storage with eight (8) individual programs and unlimited passes
Remote pendent with low voltage controls and foot pedal switch
Threaded roll shafts with micro metric flange adjustment helps eliminate spacer usage
In-line direct drive roll shaft system
Optional Anti-twist correction system for angle iron “Leg In” applications
All capacities based on mild grade materials; heavy wall and high tensile materials reduce machine capacity
