Lagun 21" / 25" x 8" Radial Drill, Models 855 & 955 - NEW

Lagun 21" / 25" x 8" Radial Drill, Models 855 & 955 - NEW
SKU #4206000
Dimensions855     |     955

Column Diameter8.3"

Column Surface to Spindle Center-Min.8.7"

Maximum Column Surface to Spindle Center29.5"     |     33.5"

Travel of Head on Arm Ways20.9"     |     24.8"

Minimum Spindle Face to Base Top10.23"     |     13.77"

Maximum Spindle Face to Base Top41.73"     |     47.63"

Arm Travel on Column (Elevating Height of Arm)23.8"     |     25.6"

Base and Column Height72.8"     |     79.1"

Maximum Machine Height From Floor85.4"     |     91.3"

Effective Area of Box Table23.6" x 17.5" x 14.9"

Dimensions of Base49.6" x 25.2" x 6.3"

Shipping Dimensions65" x 33" X 85"     |     67" x 33" X 87"

Spindle855     |     955

Spindle TaperMT #4

Stroke of Spindle8.3"

Spindle Speeds (RPM x Steps)88 to 1,500 RPM x 6

Spindle Power Feeds (Rev. x Steps)0.0019" - 0.0035" - 0.0059" x 3

Capacities855     |     955

Drilling Capacity in Steel1.5"

Drilling Capacity in Cast Iron2"

Tapping in Steel1"

Tapping in Cast Iron1.25"

Boring in Steel2.75"

Boring in Cast Iron4"

Motors855     |     955

Direct Drive Main Motor2 HP

Arm Elevating Motor1 HP

ClampingManual

Coolant Pump Motor1/8 HP

Weights855     |     955

Approximate Net Weight2,469 lb     |     2,645 lb

Approximate Gross Weight2,755 lb     |     2,945 lb
