NEW W.F. WELLS S-40-3

W.F. Wells 40″ x 40″ Semi-Automatic Horizontal Saw, Model S-40-3 – NEW

Machine Specifications
Capacity: Rectangular at 90° 25″ High X 40″ Wide , Round 25.5″
Rectangular at 45° 25″ High X 24″ Wide
Weight Capacity: 15,000 lbs
Blade Speed: 60-500 SFPM
Blade Size: 2″ X .063″ X 26′-6″
Blade Guide: Spring Tensioned Carbide Blocks with Idle Roller Backup
Blade Tension: Hydraulic
Bandwheel Size: 26″
Vise: Hydraulic
Blade Drive: 15 HP, AC Vector Drive
Sawing Force: 0-1,000 lbs
Coolant Capacity: 15 Gallons
Hydraulic Capacity: 20 Gallons
Hydraulic Drive: 5 HP Motor
Work Height: 28″
Outfeed Table: 24″ X 40″
Vise Jaw Height: 17”
Blade Tension Indicator
Blade Break/Stall Switch
Hydraulic Powered Blade Brush
Hydraulic Positioned Guide Arm
Electronic Door Interlocks
Shipping Weight: 7,000 lbs
Electrics: Wired to NFPA 79 Machine Tool Standards
Machine Dimensions: 170” Length x 55″ Width x 100″ Height
