NEW SCOTCHMAN GAA-500-90

Scotchman 20″ Automatic Upcut Circular Saw, Model SUP-500 NF – NEW

Specifications:
Round
Square
Rectangle
90°
6″ (150 mm)
6″ x 6″ (150 x 150 mm)
10″ x 3″ (250 x 75 mm)
Non Ferrous Automatic Upcut Saw designed for Aluminum, PVC, Copper, etc.
Length Tolerance
+ or – 0.006″ per index
Cutting Speed
3,000 RPM
Motor Rate
7.5 HP
Factory Wired
Specify:
230 3-ph
460 3-ph
Maximum Diameter Blade
20″ (500 mm)
Arbor Bore
1.97″ (50 mm)
Height from Floor to Vise
38-5/8″ (970 mm)
Width
77″
Depth
42″
Height
(Top of Hood) 39″
Shipping Weight
1620 lbs. (735 kg)
