Modern UE-916A Horizontal Band Saw – Semi-Automatic
Overview
Specifications
The Modern UE-916A-QS Hydraulic Horizontal Band Saw offers a large 9" × 16" cutting capacity, reliable hydraulic feed, and variable blade speeds for precision cutting of steel and other metals. Built for durability and accuracy, this saw is an excellent choice for industrial workshops and fabrication shops requiring high-performance equipment.
Model: 9×16 Horizontal Band Saw
Capacity:
90° Round: 230 mm (9")
90° Rectangle: 230 × 340 mm (9" × 13-1/2")
90° Square: 230 × 230 mm (9" × 9")
45° Round: 165 mm (6-1/2")
45° Rectangle: 230 × 165 mm (9" × 6-1/2")
Blade Size: 27 × 0.9 × 3035 mm (1" × 0.035" × 119-1/2")
Blade Wheel Diameter: 330 mm (13")
Blade Speed (FPM): 82 / 132 / 170 / 235
Blade Speed (MPM): 25 / 40 / 52 / 72
Motor:
1 PH - 1.5 HP (1.1 kW) – 1725 RPM – 60Hz
Voltage: 240V
Dimensions (L×W): 1700 × 760 mm (67" × 30")
Net Weight: 285 kg (625 lbs)
