Features
Precision positioning of rotary table, (4 x 90°) by optical projection-type reading equipment
Power operated tool clamping (MUN)
Cross and Longitudinal slide surface covered with plastic
Guideways of bed and slide are lined with hardened steel strip inserts
Speeds of faceplate and spindle may be either in conjunction or independent of each other
Central lubrication of guideways
Sliding telescopic guards (in selected areas)
Thread cutting attachment for 18 metric and 18 Whitworth threads
Standard Equipment
Built-in Faceplate
Anchoring Material
Set of Service Tools
Tailstock
Specifications
Spindle Diameter: 3.93"
Spindle Taper: ISO 50
Out Travel: 35.43"
Max. Diameter of Face Turning: 35.43"
Speed Range (23): 7.1 - 1120 RPM
Faceplate Speed (16): 7.1 - 224 RPM
Faceplate Diameter: 23.62"
Clamping Surface: 49.21" x 49.21"
Travels:
X-Axis: 62.99"
Z-Axis: 49.21"
Y-Axis: 44.09"
Voltage: 600v
Max. Table Load: 6614 LBS
Feeds (Cross, Longitudinal, Vertical, and Spindle)
Number (Per Revolution): 32
Range (Per Revolution): 0.0008" - 0.4724"
Number (Per Minute): 18
Range (Per Minute): 0.708" - 35.43"
Rapid Traverse (Per Minute): 110.24"
General
Main Drive: 15 HP
Boring Bar Support Drive: 0.55 KW, 0.75 HP
Digital Read Out
Overall Dimension: 234" x 118" x 118"
Floor Space (LxW): 264" x 118"
Overall Weight: 30,865 LBS
Excellent Condition
ST: 557
