Maximum Cutting Capacities:
TUBING
90 Degree:
Round: 8"
Square: 8"
Rectangle: 11" x 7-3/4"
45 Degree:
Round: 7"
Square: 6-1/4"
Rectangle: 7" x 6-1/4"
60 Degree:
Round: 4-1/4"
Square: 4-1/4"
Rectangle: 4-1/4" x 4"
Blade Length: 1" x 96.5"
Two Cutting Speeds (3 phase machines): 131 / 262 FPM
One Cutting Speed (1 phase machines): 196 FPM
Motor Rate: 1.3 hp (3ph), 1 kW (1ph)
Motor Options (Factory Wired): 230/460v, 3 ph; 220v, 1 ph
Width: 33-1/2"
Depth: 55"
Height: 69"
Shipping Weight (may vary): 650 lbs.
