Control: 0i-MF Plus
Travel
X axis: 1350 mm
Y axis: 700 mm
Z axis: 700 mm
Table
Work area: 1400 × 700 mm
T-slot: 7 × 18 × 100 mm
Max load: 2200 kg
Spindle
Quill taper: BBT-50
Motor power: 15 / 18 kW
Max speed: 6000 rpm
Tools
Capacity: 24 T
Max tool weight: 15 kg
Accuracy (ISO 230-2)
Accuracy: 0.010 mm
Repeatability: 0.007 mm (±0.0035 mm)
Machine
Weight: 12100 kg
Installed Options
15" touch screen with MGi and CT-50 spindle
C.C. (Chip Conveyor)
Air conditioner for electrical cabinet
Table shower system
CTS ready (Coolant Through Spindle preparation)
OTS (Tool Setter)
Handy air gun
Handy coolant gun
