Cutting Speeds (must specify when ordering):
CPO 315 HFA (ferrous): Variable Speed 11 to 177 rpm, Motor Rate: 5 hp
CPO 315 HFA NF (non-ferrous): 3,000 rpm, Motor Rate: 5 hp
Maximum Cutting Capacities (based on mild steel):
TUBING 90 Degree:
Round: 3-1/2"
Square: 3" x 3"
SOLID 90 Degree:
Round: 1-3/4"
Square: 1-1/2" x 1-1/2"
Maximum Cutting Capacities (NF) (Non-Ferrous & PVC):
SOLID (NF) 90 Degree:
Round: 3-1/2"
Square: 3" x 3"
Length Tolerance: ± 0.006" per index
Squareness Tolerance: ± 0.002" per dia. inch
Minimum Cut Length: 1/8"
Maximum Cut Length: Single Index 30", Double Index 60", Triple Index 90"
Motor Options (Factory Wired): 208/230/460v, 3 ph
Air Pressure: 90 psi
Maximum Saw Blade Diameter: 315 mm (12-3/8")
Arbor Bore Size: 40 mm (1-9/16")
Pin Spacing: 4/12/64
Dimensions: L: 100" W: 44" H: 64"
Shipping Weight (may vary): 1,800 lbs.
