Punching Capacity: 70 ton 1-1/8" in 3/4"
Special Tooling: 4" Max. Dia.
Throat Depth: 9"
Flat Bar Shear (Saber Blade - Standard): 24" Length 1/2" 3/8" x 10" 3/16" x 16" 1/8" x 24"
Angle Shear 90 degree: 6" x 6" x 1/2"
Angle Shear 45 degree w/Tool w/Bar Shear: 3" x 3" x 3/8" 4" x 4" x 3/8"
Brake 12": 45 ton
Brake 24": 45 ton
Open End Brake: Max. 1/4" x 5" (Flat or Angle Iron)
Pipe Notcher Schedule 40: 3/4", 1", 1-1/4", 1-1/2", 2"
Rectangle Notcher: 3" x 5" x 3/8"
90 degree V Notcher: 6" x 6" x 5/16"
Notching in Leg of Channel: 6" to 10"
Channel Shear: 2" to 5" adj.
Unistrut Shear: Samples Required
Rod Shear Round (max.): 9 Cavity - 1/4" to 1-1/4"
Rod Shear Square (max.): 1 Cavity - 1/4" to 1"
Square Tube Shear: 1/2" to 2" 12 gauge
Picket Tool: 1/2", 3/4" & 1" 16 gauge
Weld Coupon Bender (max.): 2" wide x 3/8"
Offset Die Holder: Max. 40 ton
Strokes per Minute in Light Material: 38 spm [Punch Station]
Strokes per Minute in Heavy Material: 15 spm [Punch Station]
Hydraulics: 3,000/3,000 psi
Motor Standard: 10 hp 208/230/460, 380/575, 3 ph
Motor Optional: 10 hp 220v, 1 ph
Dimensions: L: 63" W: 41" H: 72"
Shipping Weight (may vary): 3,800 lbs.
