CAPACITY
Swing over bed dia. mm: Ø570
Standard turning dia. mm: Ø185 (Ø200)
Maximum turning dia. mm: Ø260 (Ø200)
Swing over carriage dia. mm: Ø325
Between centers mm: 270
Bar capacity mm: Ø42
AXIS FEEDS
X axis travel mm: 20+130 (50+100)
Z axis travel mm: 250
Rapid feed - X / Z axis m/min: 30 / 30
Feed motor - X / Z axis kW: 1.8 / 1.8
JOG feed mm/min: X/Z: 0~1260
Ball screw dia x pitch mm: Ø25 x P10 (X), Ø40 x P10 (Z)
Guideway width - X / Z axis mm: 35 / 35
SPINDLE
Spindle speed rpm: 6000
Spindle nose (chuck) inch: A2-5 (6")
Spindle motor power kW: 5.5 / 7.5 / 11 (opt. 7.5 / 11 / 15)
Spindle bearing inside dia. mm: Ø80
Spindle taper -:1/20
TURRET
Tool shank size mm: 20
ax. boring bar dia. mm: Ø32 (BMT-45)
Exchange time (T-T) sec: 0.9 (opposite)
Milling speed rpm: 4000 (opt. 6000)
Milling motor kW: 2.2
TAILSTOCK (Optional)
Tailstock quill dia. mm Ø60
Quill stroke mm 80
Quill taper - M.T. #3
MACHINE
NC controller Fanuc 0i-TF (10.4")
Coolant tank capacity L: 160
Power requirement kVA: 14.4 (15.1)
Dimension LxWxH mm: 1488 x 1956 (2108) x 1775
Net weight kgs: 3700 (4070)
