NEW PARKER 583-1/2D1

Overview:
Type: Swing check valve.
Function: Permits free flow in one direction and shuts off flow in the reverse direction with very low internal leakage.
Port Size: 1/2 inch NPT female pipe threads (NPTF).
Material:
Body & Cap: Anodized aluminum alloy.
Internal Parts: Anodized aluminum alloy and stainless steel.
Seals: Synthetic rubber O-ring and molded seal.
Pressure Rating: Up to 136 Bar (2000 PSI) maximum operating pressure.
Mounting: Can be mounted in any position.
Features: Full flow with low opening pressure and improved hinge controls.
