USED 2019 DEWAY MACHINERY CO., LTD. DZJ13 LIGHTLY USED, LIKE NEW, POLISHING MACHINE.

2019 DEWAY MACHINERY CO., LTD. DZJ13 lightly used, like new, polishing machine

For pricing please click “REQUEST QUOTE” wherever you see it on our Brighton Woodworking Machinery website at www.brightonmachines.com.
Click for leasing information.
Click for shipping information.
Technical Specification:

l) Glass Thickness: 3-25(mm);

2) Minimum workable Dimension:(mm); 40X40mm

3) Working speed: 1.0-5.0m/min;

5) Number of Wheels: 12;

6) Power: 24 KW, 380 VAC, 60 Hz - UL electric components

7) Overall Dimension: (X x Y x Z); 7500 x 1200 x 2520(mm)

8) Weight: 6000 kg

Description:

1) 12 spindles(6 bottoms;3 front arris;3 back arris);

2) Bearing pads structure;

3) Toothed belt for inlet and output;

4) Height adjustable inlet conveyor;

5) CDQC motor;

6) lnnovance PLC;

7) With cerium polishing (10# bottom; 11# back arris; 12# front arris)

Configuration of grinding wheels:

Wheel specification Function Wheel Wheel control

Pos.l 150mmxl2mm lOOmesh Bottom Diamond wheel Mechanical

Pos.2 150mmx12mm 180mesh Bottom Diamond wheel Mechanical

Pos.3 150mmxl2mm 240mesh Bottom Resin wheel Mechanical

Pos.4 150mmx70mm Bottom 10S40 wheel Mechanical

Pos.5 150mmx70mm Bottom 10S40 wheel Mechanical

Pos.6 130mmxl2mm Front arris Resin wheel Mechanical

Pos.7 130mmx60mm Front arris 10S40 wheel Mechanical

Pos.8 130mmxl2mm Back arris Resin wheel Mechanical

Pos.9 130mmx60mm Back arris 10S40 wheel Mechanical

Pas.IO 150mmxl05mm Bottom Felt wheel Mechanical

Pos.11 130mmx90mm Back arris Felt wheel Mechanical

Pos.12 130mmx90mm Front arris Felt wheel Mechanical

* All Descriptions, Specifications and Features are correct to the best of our knowledge. Interested buyers should verify before purchasing.

Quality: Very Good
Electrics: 380V / 3Ph / 60 Hz
