(NEW) SCOTCHMAN H-FRAME HYDRAULIC PRESS
MODEL: PressPro 176
FACTORY SPECIFICATIONS
*Heavy Duty All-Steel Construction
*Ram Moves Laterally For Added Versatility
*Three Ram Speeds
Press Force: 176 Tons
Width Between Uprights: 43-1/4"
Width Between Table Channels: 15"
Open Height, Minimum: 7"
Open Height, Maximum: 36-1/2"
Ram Speed, Approach: 18 IPM
Ram Speed, Press: 6 IPM
Ram Speed, Return: 22 IPM
Table Height: Adjustable
EQUIPPED WITH
5 HP Motor
Joystick Operation w/Manual Jog
Removable Ram Cap To Accept A Wide Variety Of Tooling
Pressure Gauge
Hydraulic-Assist Adjustable Work Table
(2) Steel V-Blocks
Built-In Forklift Accommodations
Approximate Weight: 3450 Lbs.
Three Year Warranty
F.O.B. Philip, South Dakota
FACTORY SPECIFICATIONS SUBJECT TO MODIFICATION AND OR CHANGE
