| X | 1,050 mm | 41.339" |
| Y | 600 mm | 23.622" |
| Z | 600 mm | 23.622" |
| Power | 25 hp | 18.6 kW |
| RPM | 8,000 RPM | 8,000 RPM |
| # ATC | 30 | 30 |
| Taper | CT-40 | CT-40 |
| Table-W | 600 mm | 23.622" |
| Table-L | 1,150 mm | 45.276" |
| # Axis | 3 | 3 |
| Control | CNC (Fanuc) | CNC (Fanuc) |
Table Face to Spindle End:
125-725mm (4.9”-28.5”)
Column Face to Spindle Center:
675mm (26.6”)
Table Surface:
1150/600mm (45.3”/23.6”)
Max. Weight on Table:
1,000 kgf (2,205 lbs.)
Spindle Max. Speed:
8,000 RPM
Spindle Taper:
CAT40
Rapid Feedrate (X/Y/Z):
24/24/18 m/min (945/945/709 ipm)
Cutting Feedrate (X/Y/Z):
10 m/min (394 ipm)
Spindle Motor:
AC18.5/15 kW (25/20 hp)
Z Axis Travel:
600mm (23.6”)
Machine Height:
2887 mm (123.7”)
Approximate Weight:
7,500 kgf (16,535 lbs.)
Fanuc Oi-MF CNC Controls with Full CRT and Keyboard.
Hwacheon AI Nano Contour Control (HAI).
Cutting Feed Optimization (OPTIMA).
Efficient Contour Control (HECC) Ethernet Interface.
MIDACO 2 Position Pallet Changer.
Renishaw Probing.
Auger Chip Conveyer.
Oil Chiller.
Coolant System with Chip Conveyor.
30 Position ATC.
2 Speed & Geared Headstock.
