Parlec ER16 Collet Chuck Tool Holder 0.5mm x 10mm BT40 Taper Shank

PARLEC

ER16 COLLET CHUCK TOOL HOLDER

Collet System
ER
Collet Series
ER16
Shank Type
Taper Shank
Taper Size
BT40
Projection (Decimal Inch)
4.0000
Through Coolant
Yes
Minimum Collet Capacity (Decimal Inch)
0.0197
Minimum Collet Capacity (mm)
0.50
Maximum Collet Capacity (mm)
10.00
Maximum Collet Capacity (Decimal Inch)
0.3937
Overall Length (Decimal Inch)
6.5800
Actuator Type
Wrench
Type
ER Coolant Collet
Nose Diameter (Decimal Inch)
1.1100
PSC Code
5136
Balanced to (RPM)
25,000
TIR (Decimal Inch)
0.0002
Coolant Type
Through-Spindle & DIN Flange
Collet Nut Diameter (Decimal Inch)
1.1100
